Generating Infrastructure Overview Offline Report for Visio

In addition to regular reports that open in a web browser and can be automatically delivered, Veeam ONE offers offline reports. This is a convenient way to view report data off-site, outside the local infrastructure or its networks.

To view offline reports, you must install Veeam Report Viewer:

1. Open Veeam ONE Reporter.

For more information, see Accessing Veeam ONE Reporter.

2. Open the Workspace section.
3. In the hierarchy on the left, select Offline reports.
4. In the list of offline reports, click any report.
5. In the Actions pane, click Download Veeam Report Viewer.
6. Download the VmReportViewerSetup.msi installer file.
7. On the machine, where you want to install the Veeam Report Viewer, launch the installer file to start the Veeam Report Viewer setup wizard.
8. Follow the steps of the setup wizard to install Veeam Report Viewer.

The Infrastructure Overview report shows a diagram of the VMware vSphere and Microsoft Hyper-V infrastructure. The infrastructure is presented with a set of diagrams that illustrate different views or inventories:

• Configuration inventory
• Storage inventory
• Network inventory
• Datastore Utilization
• vMotion

To generate the Infrastructure Overview report:

1. Open Veeam ONE Reporter.

For more information, see Accessing Veeam ONE Reporter.

2. Open the Workspace tab.
3. In the hierarchy on the left, select the Offline Reports folder.
4. In the displayed list of reports, select the Infrastructure Overview report.
5. Select the Include VMs check box.
6. At the bottom of the report parameters, click Preview.

Alternatively, you can click Preview in the Actions pane on the right.

Veeam ONE Reporter will generate a file with the VMR extension and save it to the download location.

7. Open the downloaded file on the machine where Veeam Report Viewer is installed.

Veeam Report Viewer will process data in the VMR report and prepare the output. The output contains data viewable in Microsoft Visio.
