How Immutability Works

Immutability is the state of data that prevents it from being modified or deleted. Veeam Backup & Replication applies immutability to the state of a backup chain within a certain period of time. After you enable immutability, Veeam Backup & Replication prohibits deleting data from object storage repositories until the immutability expiration date comes. Immutability settings configured for object storage repository are applied to the whole backup chain and all its restore points.

To make data immutable, Veeam Backup & Replication utilizes the technology that prevents data from deletion and allows you to keep several versions of objects. The selected technology depends on the type of object storage:

• Object lock and Versioning — for Amazon S3 Storage, S3 Compatible, IBM Cloud, Wasabi Cloud.
• Version-level WORM and blob versioning — for Azure Storage.

For more information, see Enabling Immutability.

Immutability Period

Veeam Backup & Replication protects a backup chain and all its restore points during a certain immutability period. The immutability period is the number of days you have to respond to malicious actions. Within this period, you can roll back to the earlier state of your backup chain. To roll back data, you need to run Veeam PowerShell. For more information, see Rolling Back Immutable Data.

Before you configure immutability settings for your object storage repository, consider how immutability settings can influence the period within which you can restore data in case of malicious actions. The longer the immutability period, the more time you have to perform the necessary actions and roll back to the working state of your backup chain.

In both examples, a user configures a backup job with the same retention period and a backup method but a different immutability period. Thus, in the first scenario, the user has less time to react to malicious actions.

Example 1. Short Immutability Period

In this scenario, a user configures a backup job with a short immutability period. Then, the user has only 3 days to react to malicious actions. If the user is not aware of the corruption and does not attempt to restore data within 3 days, all data will be lost.

The backup job is created with the following settings:

• The backup method is forever forward incremental.
• The job retention policy is set to 30 days.
• The immutability period is set to 3 days.

On the 2nd day of a month, due to malicious actions, the settings of the backup job are modified to change the retention settings and destroy the existing backup chains:

• The job retention policy is set to 1 day.

• An active full and a couple of increments are created.

After that, the backup files that were created previously become corrupted. Since the immutability period is set to 3 days, the object storage repository keeps all states of a backup chain up to 3 days. On the 5th day, the user attempts to revert back to the state it was before the attack, but since 3 days have already passed, the state of the backup chain is not available anymore.

Example 2. Long Immutability Period

In this scenario, a user has 7 days to react to malicious actions. If the user is not aware of the corruption and does not attempt to restore data within 7 days, all data will be lost

A backup job is created with the following settings:

• The backup method is forever forward incremental.
• The job retention policy is set to 30 days.
• The immutability period is set to 7 days.

On the 2nd day of a month, due to malicious actions, the settings of the backup job are modified to change the retention settings and destroy the existing backup chains:

• The job retention policy is set to 1 day.
• An active full and a couple of increments are created.

After that, the backup files that were created previously become corrupted. The immutability period is set to 7 days, therefore, the object storage repository keeps all restore points for 7 days. On the 6th day, the user finds out the malicious actions took place, however the user still has 2 days to revert to the 1st day, find the necessary state of a backup chain and restore data.

Object Storage Actual Retention

When you configure an object storage repository, keep in mind that the immutability period affects the total number of restore points stored in the object storage repository.

Apart from the immutability period set for each object storage repository, Veeam Backup & Replication automatically adds several days to the immutability expiration date to reduce I/O operations and associated costs. This period is called Block Generation. You do not have to configure it, the Block Generation setting is applied automatically. For more information, see Block Generation.

Therefore, the actual retention should be calculated according to the following formula:

Actual retention = job retention policy + immutability period + Block Generation period

For example, the backup job is created with the following settings:

• The backup method is forever forward incremental.

• The job retention policy is set to 30 days.
• The immutability period is set to 14 days immutability.

• Default Block Generation period is 10 days (for Amazon S3 object storage and IBM Cloud object storage it is 30 days).

According to the backup job retention, an object storage repository will keep backups for 30 days. The immutability period adds extra 14 restore points as a delta that prolongs the job retention policy. Plus, 10 days from the Block Generation are on top. Thus, you need to plan storage that will be able to keep your backups for 30 + 14 + 10 days = 54 days.

Rolling Back Immutable Data

To restore data removed by the job retention policy, you need to run the Veeam PowerShell cmdlets. It will allow you to get information on a time period within which you can restore the state of a backup chain. This information will help you decide what time period suits you best and roll back the state of a backup chain. For detailed information, see description of the Get-VBRObjectStorageRepositorySyncInterval and Sync-VBRObjectStorageRepositoryEntityState cmdlets in the Veeam PowerShell Reference.

For example, your backup chain was corrupted on 6/10/2024 at 5:30:41 PM, you want to revert back prior to that period and synchronize your object storage repository with this state.

1. Before you start to synchronize the data, you get details on the details on the time period within which you can roll back a backup chain. In this example. you can select any time period within this range: 1/10/2024 4:00:53 PM to 6/11/2024 1:08:39 PM.

2. Once you get information on the time period, you can roll back the backup chain state before it was corrupted.
